325CNC-2A-1S

The 50CNC-3A-1S is a high-performance fully automatic CNC pipe bender. The name “50” indicates a maximum bending capacity of 50 mm pipe diameter, “CNC” stands for Computer Numerical Control, “3A” typically refers to three servo axes (feeding, bending, and lifting) working in coordination, and “1S” denotes a set of molds. This equipment integrates precision machinery, servo drives, and CNC systems to efficiently and accurately perform complex spatial bending operations. Operators only need to input programs, and the machine can automatically complete feeding, rotating, bending, and spatial cornering movements. With high repeatability positioning accuracy, it significantly enhances production efficiency and product consistency.

This heavy-duty fully automatic pipe bending machine adopts Japanese MITSUBISHI servo, industrial computer TPC6000 controller, Japanese Mitsubishi high-performance FX5U series + multi-axis motion controller + optical fiber communication. 15-inch color industrial computer, movable control console for easy operator use.

Fully automatic CNC tube bending machine, tube bending and mold transfer servo control (hydraulic control is available), cornering and feeding are servo controlled, clamping and core pulling are hydraulically controlled. It can achieve large radius bending and has push bending function. The equipment uses a 10.0-inch touch screen, English or multiple language modes, PLC controller (optional Windows XP industrial system). Air cooling/water cooling/oil cooling are available. It has a partial automatic lubrication function. Electrical and hydraulic components are imported from Japan, France, Germany and other countries.

Precise control through 4-13 axis servo motors;

Can realize left and right bending functions of 1-4 layer molds;

Can realize large radius or spiral product bending, with push bending function;

Industrial computer system has 3D interference inspection function;

Can connect robots and 3D measuring instruments, etc.
